2016 Aston Martin DB9 GT (US-Spec)

2016 Aston Martin DB9 GT (US‑Spec)

By Arthur Demi via Aston Martin

Quick Specs

Engine 6L V12

Power 540 bhp

Torque 457 lb ft

0-62 mph 4.5 sec.

Top Speed 183 mph

Aston Martin DB9 GT (US-Spec)

The Aston Martin DB9 GT is the most elegant expression of a sports grand tourer, its DNA echoing the iconic DB GT models of its lineage.

Delivering enhanced power and with subtle new touches to highlight its famously seductive styling, the DB9 GT is the ultimate incarnation, the embodiment of faultless form and formidable function, the beating heart of Aston Martin.

Intrinsically desirable yet quietly understated, its beautifully sculptured form is given only subtle accents to hint at the potency of its 540 brake horsepower 6.0-liter V12 engine.

More captivating than ever, the DB9 GT is a potent distillation of DB9’s already intoxicating blend of agile sports car and elegant grand tourer. Designed with passion, crafted with meticulous attention to detail, and true to the legacy of its bloodline, this is the ultimate incarnation of Aston Martin’s iconic sports car.

Featuring luxurious fluted leather seats, evocative GT badging, and a sweeping waterfall fascia with intuitive new AMi II infotainment system, the craft and passion of the DB9 GT speaks to the soul, a whisper to the heart-stopping thrills that await.



  • Two-door coupe body style with 2+2 seating configuration
  • Extruded bonded aluminium VH body structure
  • Aluminium, magnesium alloy and composite body
  • Extruded aluminium door side impact beams
  • Single bi-xenon headlamps with integrated LED side lights and direction indicators
  • Clear LED rear lamps


  • All-alloy, quad overhead camshaft, 48 valve, 5,935cc, V12
  • Front mid-mounted engine, rear-wheel drive
  • Fully catalysed stainless steel exhaust system with active bypass valves
  • Max power: 540 bhp (547 PS) at 6,750 rpm
  • Max torque: 620 Nm (457 lb ft) at 5,500 rpm
  • Acceleration: 0-100 km/h (0-62 mph) in 4.5 seconds
  • Max speed: 295 km/h (183 mph)


  • Rear mid-mounted ‘Touchtronic 2’ six-speed transmission with electronic shift-by-wire control system
  • Alloy torque tube with carbon fibre propeller shaft
  • Limited-slip differential
  • Final drive ratio 3.46:1

Wheels and Tires

  • 10-spoke Silver Diamond Turned wheels
  • Front wheel: 8.5J x 20-inch
  • Rear wheel: 11J x 20-inch
  • Front tire: Pirelli P Zero 245/35 ZR20
  • Rear tire: Pirelli P Zero 295/30 ZR20
  • Tire repair kit


  • Length: 4720mm (inc. front number plate plinth)
  • Wheelbase: 2740mm
  • Width: 2061mm (inc. mirrors)
  • Fuel tank capacity: 78 litres (17.15 Imp.galls, 20.6 US galls)
  • Height: 1282mm Weight: 1785 kg - Coupe 1890 kg - Volante


  • Rack and pinion, servotronic speed-sensitive power-assisted steering, 3.0 turns lock-to-lock
  • Column tilt and reach adjustment


  • Front: ventilated carbon ceramic discs, 398 mm diameter with six-piston monobloc calipers
  • Rear: ventilated carbon ceramic discs, 360 mm diameter with four-piston monobloc calipers
  • Dark anodised brake calipers
  • Dynamic Stability Control (DSC) with track mode
  • Anti-lock Braking System (ABS)
  • Electronic Brakeforce Distribution (EBD)
  • Emergency Brake Assist (EBA)
  • Traction control (TC)


  • 3-stage Adaptive Damping System (ADS) with Normal, Sport and Track modes
  • Front: independent double wishbones incorporating anti-dive geometry, coil springs, anti-roll bar and monotube adaptive dampers
  • Rear: independent double wishbones with anti-squat and anti-lift geometry, coil springs, anti-roll bar and monotube adaptive dampers

Standard Features

Aston Martin DB9 GT (US-Spec)

  • Full-grain leather interior
  • Piano Black facia trim with Iridium trim pack
  • Alcantara steering wheel (leather for the Volante)
  • GT headrest embroidery
  • Electrically adjustable sports seats with side airbags
  • Memory seats & exterior mirrors (three positions)
  • Alcantara fluted effect headlining
  • Dual-stage driver/front passenger front airbags
  • Powerfold exterior heated mirrors
  • Heated rear screen
  • Automatic temperature control
  • Organic Electroluminescent (OEL) displays
  • Trip computer
  • Cruise control
  • Bluetooth® telephone preparation1
  • Satellite navigation1,2
  • Satellite radio system (USA only) 1
  • Front and rear parking sensors
  • Tire pressure monitoring system1
  • Alarm and immobiliser
  • Remote-control central door locking and boot release
  • Glass ECU
  • LED map-reading lights
  • 700-watt Aston Martin Premium audio system with Dolby® Pro Logic II®
  • Integrated Apple iPod®,4 connector
  • DAB radio
  • USB Connector with Waveform Audio Format (WAF), Windows Media Audio (WMA) and MPEG (MP3) audio file compatibility
  • 3.5 mm auxiliary input socket
  • Gloss black painted splitter and diffuser
  • Rear lamps with black border surround
  • Sports exhaust
  • Auto-dimming interior rear-view mirror1
  • Rear Parking Assist Camera

Optional Features

  • Volante body style
  • 5-spoke Silver wheels
  • 5-spoke Gloss Black Diamond Turned wheels
  • 10-spoke Gloss Black Diamond Turned wheels
  • Alternative brake caliper finish – black, red, grey and yellow
  • Carbon fibre splitter and diffuser
  • Carbon fibre side strakes
  • Carbon fibre rear lamp infills
  • Carbon fibre door handles
  • Carbon fibre mirror caps and arms
  • Exterior Carbon Fibre Pack (comprising mirror caps and mirror arms, side strakes, and rear lamp infills)
  • Black DLO
  • AM Wings headrest embroidery
  • Duotone leather pack –including seat inserts, door inserts and headlining
  • Heated front seats
  • Auto-dimming interior rear-view mirror1
  • Boot-mounted umbrella
  • Optional facia trims - Ashburl Light, Piano Ice Mocha, Carbon Fibre, Cuprum Carbon Fibre
  • Optional trim packs – Piano Black, Piano Ice Mocha, Carbon Fibre
  • Colour keyed leather steering wheel or One-77 steering wheel
  • Matching wood door trim (not available with B&O BeoSound audio system options)
  • Personalised sill plaques
  • 16GB USB drive
  • 1000-watt Bang & Olufsen BeoSound audio system with ICEpower technology (including USB drive)
  • Auto-dimming interior rear-view mirror with garage door opener 1
  • Alarm upgrade (volumetric and tilt sensor)
  • Satellite radio system (Canada only) (excludes subscription)
  • Tracking device (UK category five)
  • First-aid kit
  • Trinket tray
  • Satellite radio system1
  • Second Glass ECU
  • Fluted, micro perforated Leather headlining
  • Leather ECU pouch
(Source: Aston Martin)
