2017 Porsche Panamera Turbo

2017 Porsche Panamera Turbo

By Arthur Demi via Porsche

2017 Panamera Turbo

The Panamera Turbo is now the most powerful model in the range. Its 4.0-liter twin-turbo V8 develops 550 hp at 5,750 rpm and a maximum torque of 567 lb-ft between 1,960 and 4,500 rpm. It has 30 hp more than the previous model, and its maximum torque has been increased by 51 lb-ft. The eight-cylinder engine is capable of propelling the Panamera Turbo from 0 to 60 mph in 3.6 seconds; with the Sport Chrono Package, this time is reduced to just 3.4 seconds. The Panamera Turbo can reach a top track speed of 190 mph, and has a weight of 4398 pounds according to DIN measurement. These are impressive figures that illustrate just how easily the engine can propel the Panamera with its power-to-weight ratio of just 8 lbs/hp.

Specifications

Engine

Panamera 4SPanamera Turbo
TypeV6 twin turboV8 twin turbo
No. of cylinders68
Valves/cylinder44
Displacement2,894 cm33,996 cm3
Bore84.5 mm86.0 mm
Stroke86.0 mm86.0 mm
Max. power output324 kW (440 hp)404 kW (550 hp)
at engine speed5,650 – 6,600 rpm5,750 – 6,000 rpm
Max. torque550 Nm770 Nm
at engine speed1,750 – 5,500 rpm1,960 – 4,500 rpm
Max. output per litre111.7 kW/I (151.7 hp/l)101.0 kW/l (137.5 hp/l)
Compression ratio10.5:110.1:1
Maximum engine speed6,800 rpm6,800 rpm
Cooling systemWater cooling, thermal management with control thermostat and potted water pump
Valve controlVarioCam Plus: adjustment of intake and exhaust camshafts, valve stroke switching on intake camshaft VarioCam Plus with adaptive cylinder control: adjustment of intake and exhaust camshafts, cylinder deactivation via two-stage sliding cams on intake and exhaust camshafts

Power transmission

Panamera 4SPanamera Turbo
Drive systemPorsche Traction Management (PTM): active all-wheel drive with electronically- and map-controlled multiplate clutch, variable torque distribution between front and rear axles
Transmission8-speed Porsche Doppelkupplung (PDK)
Gear ratios
1st gear5.975.97
2nd gear3.243.24
3rd gear2.082.08
4th gear1.421.42
5th gear1.051.05
6th gear0.840.84
7th gear0.680.68
8th gear0.530.53
Reverse gear5.225.22
Rear axle3.363.15

Chassis

Panamera 4SPanamera Turbo
Springing and dampingSteel springs with Porsche Active Suspension Management (PASM)Adaptive air suspension with three-chamber air springs and Porsche Active Suspension Management (PASM)
Front axleAluminium double wishbone suspension, independent wheel suspensions
Rear axleAluminium multi-link suspension with subframe, independent wheel suspensions
SteeringElectromechanical servo steering; optional rear axle steering (HAL)
Steering ratio15.5:1 (centre position) up to 9.3:1; with rear axle steering (HAL) 14.2:1 (centre position) up to 9.3:1
Steering wheel diameter375 mm
Turning circle diameter11.9 m; with rear axle steering (HAL) 11.4 m
Driving stability systemPorsche Stability Management (PSM) incl. ABS with extended brake functions
Brakes
Brake systemSix-piston aluminium monoblock fixed calliper brakes, front; four-piston aluminium monoblock fixed calliper brakes, rear
Brake discs, front axleGrey cast iron, internally vented
Diameter360 mm410 mm
Thickness36 mm38 mm
Brake discs, rear axleGrey cast iron, internally vented
Diameter330 mm380 mm
Thickness28 mm30 mm
Wheels and tyres
Wheels with tyres, front9 J x 19 ET 64 with 265/45 ZR 19 tyres 9.5 J x 20 ET 71 with 275/40 ZR 20 tyres
Wheels with tyres, rear10.5 J x 19 ET 62 with 295/40 ZR 19 tyres 11.5 J x 20 ET 68 with 315/35 ZR 20 tyres

Dimensions

Panamera 4SPanamera Turbo
Length5.049 mm
Width (with door mirrors)1.937 mm(2.165 mm)
Height1.423 mm1.427 mm
Wheelbase2.950 mm
Track width, front (wheel size)1.671 mm (19”)1.657 mm (20”)
Track width, rear (wheel size)1.651 mm (19”)1.639 mm (20”)
Luggage volumes and weights
Luggage volumes495 – 1,304 l
Unladen weight (DIN)1,870 kg1,995 kg
Allowable gross weight2,495 kg2,585 kg
Weight-to-power ratio4.3 kg/hp3.6 kg/hp
Driving performance
Top speed289 km/h306 km/h
Acceleration
0-60 mph4.2 s3.6 s
0-60 mph with Sport Plus4.0 s3.4 s
0-100 km/h4.4 s3.8 s
0-100 km/h with Sport Plus4.2 s3.6 s
0-160 km/h10.3 s8.4 s
0-160 km/h with Sport Plus10.0 s8.1 s
0-200 km/h16.2 s13.0 s
0-200 km/h with Sport Plus15.9 s12.7 s

Porsche Panamera Turbo

Fuel and emissions

Panamera 4SPanamera Turbo
Emissions standardEuro 6
Fuel typeSuper Plus (98 RON)
Fuel consumption Urban10.2 – 10.1 l/100 km12.9 – 12.8 l/100 km
Extra-urban6.8 – 6.7 l/100 km7.3 – 7.2 l/100 km
Combined8.2 – 8.1 l/100 km9.4 – 9.3 l/100 km
CO2 emissions Combined186 – 184 g/km214 – 212 g/km
Efficiency class in GermanyCD
Fuel tank capacity (optional)75 l (90 l)90 l
Aerodynamics
Air drag coefficient, cd0.290.3
Frontal area A2.37 m²2.38 m²
cd x A:0.6870.714
(Source: Dr. Ing. h.c. F. Porsche AG)
